Voice and Data Cabling

Types of Cabling

  • Category 3
  • Category 5/5e
  • Category 6
  • Fiber
  • Coaxial

Cabling Details

Category 3:

Cabling systems are categorized by the levels of data they are able to sustain.  Category 3, commonly referred to as Cat-3, is an unshielded twisted pair (UTP) cable designed to carry a maximum data rate of 10Mbit/s and bandwidth of 16MHz.  It is part of a copper cabling family and is recognized by its defining standard, TIA/EIA-568-B.

Cat-3 was a very popular format in the early 1990’s, but has since been replaced in favor of the higher performance Cat-5 cable standard.  For the last decade, most new cable installations have been built with Cat-5e or Cat-6.  Category 3 is still being used for two-line telephone systems and unlike Cat-4, 5/5e and 6 it is still recognized by the TIA/EIA-568-B standard.

While Cat-3 and Cat-5e look identical, Cat-3’s lower specifications tend to cause more errors at higher speeds.  Cat-3 is compatible with the original PoE (Power over Ethernet) specifications, though it does not support 802.3at Type 2 high-power variation.  Cat-5e is certified for a maximum of 100 MHz, while Cat-3 is only rated for 16 MHz.  Category 3 was designed for voice and data transmissions up to 10 Mbit/s, but also runs Ethernet 10BASE-T.

Category 5e:

Category 5 (Cat-5) cable is also a twisted pair cable used for carrying signals.  Cat-5 is used in structured cabling for networks such as Ethernet, telephony and video.  Most Category 5 cables are unshielded and rely on twist pair design for noise rejection.  Cat-5 cable has been superseded by Category 5e (Cat-5e), which is an enhanced version of Cat-5.  Category-5e has formally been recognized as the standard since 2001.

Cat-5e is the most common cable for data networks.  Category 5e is defined as the TIA/EIA-568-B standard with clarification in TBS-95.  The specified performance and test requirements are for frequencies up to 100MHz.  Cat-5e offers twisted pair cables in two main varieties, solid and stranded.  Solid cable will support longer length runs and operates best in fixed wiring configurations.  Stranded cable is more pliable and better suited for shorter distance moveable cabling.  Cat-5e can be bent at any radius that exceeds four times the diameter of the cable.  Most Category 5e cables are connected using 8P8C modular connects, commonly referred to as RJ45 inappropriately.

Cat-5e is not rated for outdoor use and operates at temperatures from -10C to 60C.  If being used outdoors, a conduit is required in order to protect it from moisture and lightning.  The maximum length for a cable segment is 328 feet, therefor any longer runs will require a repeater or switch.

Category 5e cabling is commonly used for faster Ethernet networks, such as 100BASE-TX and 1000BASE-T.  10BASE-T and 100BASE-TX Ethernet connections require two cable pairs.  1000BASE-T requires four cable pairs.  Cat-5 is rated for 100M, while Cat-5e is rated for 350M.

Category 6:

Category 6 (Cat-6) cable is a cable standard for Gigabit Ethernet and is backward compatible with Cat-5, Cat-5e and Cat-3 cable standards.  It offers high quality transmission of data at more than twice that of Cat-5e.  Category 6 provides performance up to 250 MHz and 1000Mbit/s.

Like the other twisted pair cables, Cat-6 has four twisted wire pairs.  It is the 6th generation of twisted pair Ethernet cabling and is made with 23 gauge wire.  Category 6 is suitable for 10 BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX and 10GBASE-T.  Cat-6 cables are normally terminated in 8P8C modular connectors and use either T568A or T568B pin assignments.

Cat-6 connectors help reduce noise, as well as lower attenuation.  Category 6 may be used for security systems and telephone services, while having superior transmission performance to the Cat-5e cable.  All these features are why many consider Cat-6 cabling the predominant media in the structured cabling market.

Fiber:

Fiber optic cables are those which contain one or more optical fibers.  They use light pulses to transmit information down fiber lines.  They are typically individually coated with plastic layers and contained in a protective tube.  Fiber optics are replacing traditional copper lines due to their large carrying capacity and ability to transmit signals a greater distance without the need of refreshing.

Modern fiber cables can hold up to a thousand fibers in a single cable and have potential bandwidth in the Terabytes per second range.  Fiber optic cable has become cheaper over time and the cost of small fiber-count-pole-mounted cables has greatly decreased.  It is estimated that no more than 1% of the optic fiber buried in recent years is actually “lit”.

While copper cable cost less per square foot, fiber optic cable has much more capacity.  Connectors and other equipment needed to install fiber optics are also more expensive.  The ends must be cleaved when joining lengths of optical fiber and therefor require special connectors.

An optical fiber link in a commercial network will allow the transmittal of ten billion digital bits per second. Telephone calls numbering in the tens of thousands could be carried. Fibers consist of two layers of silica glass; the core and the cladding enclosed in a protective sheath.  Plastic optical fiber (POF) is a newer, plastic-based cable. POF promises performance similar to glass. POF will cost less than glass fibers but will only be used on very short runs.
